Exploded View Parts Ordering: 3613-2_151

3613-2 151 Online Parts Manual

Serial No: 151-59101

Download PDF Version

Return to manuals

Page Code: C-9-62

Click for Larger View
Index No Ref. Part Number Description Units Per Assembly Availability Price
Index No Ref.: Ref. Part Number: 51742 Description: Hydraulic Contour Feed Assembly (3613-2) Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: Ref. Part Number: 59663 Description: Hydraulic Contour Feed Assembly (3613-1, 3613-10) Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: Ref. Part Number: 55601 Description: Hydraulic Contour Feed Assembly (3612, 3613-0, 3612-1) Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: 1 Part Number: 090-118761 Description: Pump (3613-2, 3612, 3612-1, 3613-0) Units Per Assembly: Use Availability: Call For Info Price:
Index No Ref.: Part Number: 090-022815 Description: Pump (3613-1, 3613-10) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 2 Part Number: 090-020520 Description: Pulley Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 3 Part Number: 091-980326 Description: Screw, Hex. Hd. Cap 5/16-18NC x 1-3/4 Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 4 Part Number: 091-992628 Description: Washer 5/16" Std Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 5 Part Number: 091-071084 Description: Male Connector (3613-2) Units Per Assembly: Use Availability: Call For Info Price:
Index No Ref.: Part Number: 090-014010 Description: Male Connector (3613-1, 3613-10) Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: Part Number: 090-081381 Description: Male Connector (3612, 3613-0, 3612-1) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 6 Part Number: 090-052093 Description: "A" Belt (50 Cycle) Units Per Assembly: Use Availability: In Stock Price: $11.09
Index No Ref.: Part Number: 091-066951 Description: "A" Belt (60 Cycle) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 7 Part Number: 091-055707 Description: Pulley (50 Cycle) Units Per Assembly: Use Availability: Call For Info Price:
Index No Ref.: Part Number: 091-042226 Description: Pulley (60 Cycle) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 8 Part Number: 090-002114 Description: Nylon Tube 3/8 O.D. Units Per Assembly: A.R. Availability: Call For Info Price:
Index No Ref.: 9 Part Number: 091-071084 Description: 90 Degree Male Elbow Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 10 Part Number: 090-014036 Description: 90 Degree Male Elbow Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 11 Part Number: 090-095456 Description: Cross Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 12 Part Number: 105-046122 Description: Pipe Plug Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 13 Part Number: 090-133836 Description: Female To Male Run Tee Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 14 Part Number: 114-035074 Description: Nipple Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 15 Part Number: 091-135848 Description: 45 Degree Male Elbow Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 16 Part Number: 090-403296 Description: Tank Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 17 Part Number: 090-023334 Description: Cap Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 18 Part Number: 117-135053 Description: Relief Valve (Ass'y #51742) Units Per Assembly: Use Availability: Call For Info Price:
Index No Ref.: Part Number: 091-236554 Description: Relief Valve (Ass'y #59663) Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: Part Number: 091-236539 Description: Relief Valve (Ass'y #55601) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 19 Part Number: 091-160739 Description: Escutcheon Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 20 Part Number: 090-484098 Description: Bracket Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 21 Part Number: 090-058470 Description: Grommet Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 22 Part Number: 090-212127 Description: Dip Stick Sub-Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 23 Part Number: 105-115109 Description: Breather Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 24 Part Number: 091-980466 Description: Screw, Hex. Hd. Cap 3/8-16NC x 1 Units Per Assembly: 6 Availability: Call For Info Price:
Index No Ref.: 25 Part Number: 091-991265 Description: Nut, Hex. 3/8-16NC Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 26 Part Number: 091-993329 Description: Washer, Lock 3/8 Std Units Per Assembly: 6 Availability: Call For Info Price:
Index No Ref.: 27 Part Number: 091-980268 Description: Screw, Hex. Hd. Mach. 5/16-18NC x 5/8 Units Per Assembly: 4 Availability: Call For Info Price:
Index No Ref.: 28 Part Number: 091-991224 Description: Nut, Hex. 5/1 6-18NC Units Per Assembly: 6 Availability: Call For Info Price:
Index No Ref.: 29 Part Number: 091-993238 Description: Washer, Lock 5/16" Std. Units Per Assembly: 4 Availability: Call For Info Price:
Index No Ref.: 30 Part Number: 090-195090 Description: Jiffy Strap Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 31 Part Number: 091-988931 Description: Screw, Rd. Hd. Mach. 1/4-20NC x 3/8 Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 32 Part Number: 090-000019 Description: Rubber Hose 1/2" I.D. x3/4" O.D. Units Per Assembly: A.R. Availability: Call For Info Price:
Index No Ref.: 33 Part Number: 135-050136 Description: Chain Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 34 Part Number: 135-052140 Description: Contour Feed Ass'y (3613-2, 3613-1, 3613-10) (See Detail) Units Per Assembly: Use Availability: Call For Info Price:
Index No Ref.: Part Number: 135-052124 Description: Contour Feed Ass'y (3612, 3613-0, 3612-1) (See Detail) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 35 Part Number: 090-002114 Description: Nylon Tube 3/8" O.D. Units Per Assembly: A.R. Availability: Call For Info Price:
Index No Ref.: 36 Part Number: 090-002114 Description: Nylon Tube 3/8" O.D. Units Per Assembly: A.R. Availability: Call For Info Price:
Index No Ref.: 37 Part Number: 090-172479 Description: Clamp Units Per Assembly: 4 Availability: Call For Info Price:
Index No Ref.: 38 Part Number: 091-988543 Description: Screw, Rd. Hd. Mach. 8-32NC x 1/2 Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 39 Part Number: 134-174010 Description: Thumb Screw Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 40 Part Number: 135-006716 Description: Horizontal Roller Ass'y (3613-1, 3613-2, 3613-10) Units Per Assembly: Use Availability: Call For Info Price:
Index No Ref.: Part Number: 091-066639 Description: Horizontal Roller Ass'y (3612, 3613-0, 3612-1) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 41 Part Number: 135-075919 Description: Roller Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 42 Part Number: 091-988857 Description: Screw, Rd. Hd. Mach. 10-32NF x 1/2 (3613-1, 3613-2, 3613-10) Units Per Assembly: Use Availability: Call For Info Price:
Index No Ref.: Part Number: 091-987560 Description: Screw, Flat Hd. Mach. 10-32NFx 1/2 (3612, 3613-0, 3612-1) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 43 Part Number: 091-038455 Description: Washer (3612, 3613-0, 3612-1) Units Per Assembly: Use Availability: Call For Info Price:
Index No Ref.: Part Number: 135-075927 Description: Washer (3613-1, 3613-2, 3613-10) Units Per Assembly: One Availability: Call For Info Price:
Index No Ref.: 44 Part Number: 135-020055 Description: Guide & Post Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 45 Part Number: 106-233380 Description: Washer Units Per Assembly: A.R. Availability: Call For Info Price:
Index No Ref.: Part Number: Description: Following Items Not Shown: Units Per Assembly: Availability: Price:
Index No Ref.: Part Number: 135-008324 Description: Cover Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 091-993964 Description: Drive Screw Units Per Assembly: 4 Availability: Call For Info Price:
