Exploded View Parts Ordering: 3612-3_153

3612-3 153 Online Parts Manual

Serial No: 153-59101 End Date 153-761249

Return to manuals

Page Code: CM-2-60

Click for Larger View
Index No Ref. Part Number Description Units Per Assembly Availability Price
Index No Ref.: Ref. Part Number: 503543 Description: Head Assembly Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: 1 Part Number: 5918 Description: Dowel Pin Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 2 Part Number: 100189 Description: Swivel Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 3 Part Number: 100402 Description: Radius Washer Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 4 Part Number: 199507 Description: Cotter Pin Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 5 Part Number: 3355 Description: Casing Clamp Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 6 Part Number: 198406 Description: Screw, Soc. Set Cup Pt. #8-32NC x 1/4 Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 7 Part Number: 109825 Description: Casing Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 9 Part Number: 100085 Description: Pivot Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 10 Part Number: 199319 Description: Washer, Lock #10 Std Units Per Assembly: 2 Availability: In Stock Price: $4.20
Index No Ref.: 11 Part Number: 100190 Description: Crank Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 12 Part Number: 35-8582 Description: Ext. Retaining Ring Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 13 Part Number: 100846 Description: Link Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 14 Part Number: 100404 Description: Pin Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 15 Part Number: 4617 Description: Ext. Retaining Ring Units Per Assembly: 4 Availability: Call For Info Price:
Index No Ref.: 16 Part Number: 28527 Description: Handle Assembly Units Per Assembly: 1 Availability: In Stock Price: $162.14
Index No Ref.: Part Number: 34-05513 Description: Handle Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 45330 Description: Handle Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 17 Part Number: 198869 Description: Screw, Rd. Hd. Mach. #10-24NC x 1/2 Units Per Assembly: 3 Availability: Call For Info Price:
Index No Ref.: 18 Part Number: 3048 Description: Spring Clip Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 19 Part Number: 402127 Description: Head Sub-Assembly (See Detail) Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 20 Part Number: 22237 Description: Wheel Hinge Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 21 Part Number: 13407 Description: Spacer Units Per Assembly: A.R. Availability: Call For Info Price:
Index No Ref.: 22 Part Number: 17827 Description: Spacer Units Per Assembly: A.R. Availability: Call For Info Price:
Index No Ref.: 23 Part Number: 198075 Description: Screw, Hex. Hd. Cap 1/2-13NC x 3 3/4 Units Per Assembly: 3 Availability: Call For Info Price:
Index No Ref.: 24 Part Number: 199327 Description: Washer, Lock 1/2 Std Units Per Assembly: 3 Availability: In Stock Price: $4.20
Index No Ref.: 25 Part Number: 5916 Description: Lockbolt Units Per Assembly: 3 Availability: Call For Info Price:
Index No Ref.: 26 Part Number: 199145 Description: Nut, Jam 7/8-14NF Units Per Assembly: 3 Availability: Call For Info Price:
Index No Ref.: 27 Part Number: 402199 Description: Saw Guard Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 28 Part Number: 198030 Description: Screw, Hex. Hd. Cap 5/16-18NC x 1 1/4 Units Per Assembly: 5 Availability: Call For Info Price:
Index No Ref.: 29 Part Number: 199323 Description: Washer, Lock 5/16 Std Units Per Assembly: 5 Availability: In Stock Price: $4.20
Index No Ref.: 30 Part Number: 5-01304 Description: Spring Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 31 Part Number: 198901 Description: Screw, Rd. Hd. Mach. 1/4-20NC x 1 1/2 Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 32 Part Number: 44579 Description: Taper Wheel Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 46931 Description: Taper Wheel Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 27437 Description: Tire and Rim Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 31452 Description: Back-up Plate Units Per Assembly: 6 Availability: In Stock Price: $56.30
Index No Ref.: Part Number: 199015 Description: Screw, Truss Hd. Mach. #10-24NC x 3/8 Units Per Assembly: 22 Availability: In Stock Price: $4.20
Index No Ref.: Part Number: 4675 Description: Retainer Units Per Assembly: 2 Availability: In Stock Price: $17.45
Index No Ref.: 34 Part Number: 35-8610 Description: Hinge Pin Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 35 Part Number: 198851 Description: Screw, Rd. Hd. Mach. #8-32NC x 1/4 Units Per Assembly: 3 Availability: Call For Info Price:
Index No Ref.: 36 Part Number: 199257 Description: Washer, Flat #8 Std Units Per Assembly: 1 Availability: In Stock Price: $4.20
Index No Ref.: 37 Part Number: 121805 Description: Post Scale Pointer Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: Description: Following items not shown: Units Per Assembly: Availability: Price:
Index No Ref.: Part Number: 45716 Description: Tension Indicator Assembly Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 17478 Description: Bezel Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 198867 Description: Screw, Rd. Hd. Mach. #10-24NC x 3/8 Units Per Assembly: 4 Availability: In Stock Price: $4.20
