Exploded View Parts Ordering: 3612-3_153

3612-3 153 Online Parts Manual

Serial No: 153-59101 End Date 153-761249

Return to manuals

Page Code: CM-2-33

Click for Larger View
Index No Ref. Part Number Description Units Per Assembly Availability Price
Index No Ref.: Ref. Part Number: 55838 Description: Head Ass'y. (1612-X1) Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: Ref. Part Number: 54674 Description: Head Ass'y. (1613-2, 3613-2, 1612-3 & 3612-3) Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: 1 Part Number: 48846 Description: Head Sub -Ass'y Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 2 Part Number: 5919 Description: Grease Fitting Units Per Assembly: 2 Availability: In Stock Price: $4.20
Index No Ref.: 3 Part Number: 57465 Description: Head Casting Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 4 Part Number: 41027 Description: Slide Block Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 6 Part Number: 28526 Description: Screw Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 7 Part Number: 5-01414 Description: Collar Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 8 Part Number: 4261 Description: Roll Pin Units Per Assembly: 2 Availability: In Stock Price: $1.28
Index No Ref.: 9 Part Number: 35-8615 Description: Thrust Bearing Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 10 Part Number: 100083 Description: Rod Anchor Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 11 Part Number: 100397 Description: Adaptor Units Per Assembly: 1 Availability: In Stock Price: $68.54
Index No Ref.: 12 Part Number: 35-328 Description: Dowel Pin Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 13 Part Number: 35-9473 Description: Grease Fitting Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 14 Part Number: 100405 Description: Spring Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 15 Part Number: 35-9190 Description: Insert Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 16 Part Number: 35-9188 Description: Spring Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 17 Part Number: 49340 Description: Post Guide Block Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 18 Part Number: 35-9189 Description: AdJ. Screw Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 19 Part Number: 5-01401 Description: Dowel Pin Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 20 Part Number: 34668 Description: Gib Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 21 Part Number: 54282 Description: Post Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 22 Part Number: 22130 Description: Gear Rack Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 23 Part Number: 100404 Description: Pin Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 24 Part Number: 4617 Description: Ext. Ret. Ring Units Per Assembly: 4 Availability: Call For Info Price:
Index No Ref.: 25 Part Number: 100846 Description: Link Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 26 Part Number: 101139 Description: Casing (1612-X1, 1613-2, & 1612-3) Units Per Assembly: USE Availability: Call For Info Price:
Index No Ref.: 27 Part Number: 109825 Description: Casing (3613-2 & 3612-3) Units Per Assembly: ONE Availability: Call For Info Price:
Index No Ref.: 28 Part Number: 3355 Description: Casing Clamp Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 29 Part Number: 5880 Description: Scr. Soc. Hd. Set Cone Pt. Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 30 Part Number: 100189 Description: Swivel Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 31 Part Number: 100402 Description: Radius Washer Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 32 Part Number: Comm. Description: Cotter Pin 1/16 Dia. x 1/2 Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 33 Part Number: 100085 Description: Pivot Ass'y Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 34 Part Number: 100190 Description: Crank Ass'y Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 100191 Description: Bell Crank Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 100192 Description: Spacer Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 35 Part Number: 35-8582 Description: Ext. Ret. Ring Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 36 Part Number: 28527 Description: Handle Ass'y Units Per Assembly: 1 Availability: In Stock Price: $162.14
Index No Ref.: 37 Part Number: 5918 Description: Dowel Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 38 Part Number: 5916 Description: Lock Bolt Units Per Assembly: 3 Availability: Call For Info Price:
Index No Ref.: 39 Part Number: 6-01306 Description: Post Scale Pointer Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 40 Part Number: 34-08502 Description: Washer Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 41 Part Number: 21389 Description: Post Chip Guard Sub-Ass'y Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 42 Part Number: 5-01304 Description: Post Chip Guard Spring Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 43 Part Number: Comm. Description: Scr. Rd. Hd. Mach. 1/4-2ONC x 1 1/2" Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 44 Part Number: 44993 Description: Saw Guard Ass'y. Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 45003 Description: Saw Guard Sub-Ass'y. Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 42772 Description: Slide Guard Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Part Number: 35-2016 Description: Wing Nut Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 45 Part Number: 4269 Description: Dowel Units Per Assembly: 1 Availability: In Stock Price: $1.28
Index No Ref.: 46 Part Number: 22237 Description: Wheel Hinge Ass'y. Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 47 Part Number: Comm. Description: Nut, Jam 1/4-20NC Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 48 Part Number: 3862 Description: Screw, Set Dog Pt. Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 49 Part Number: 22268 Description: Wheel Hinge Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 50 Part Number: 27016 Description: Hub Units Per Assembly: 1 Availability: In Stock Price: $1,652.19
Index No Ref.: 51 Part Number: 16638 Description: Tilt Lock Knob Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 52 Part Number: 5-01108 Description: Tilt Knob Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 53 Part Number: 16408 Description: Wheel Axis Stud Units Per Assembly: 1 Availability: In Stock Price: $612.32
Index No Ref.: 54 Part Number: 5-01425 Description: Tilt Screw Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 55 Part Number: 35-7596 Description: Ret. Ring Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 56 Part Number: 16538 Description: Bearing Units Per Assembly: 2 Availability: In Stock Price: $115.71
Index No Ref.: 57 Part Number: 13407 Description: Spacer Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 58 Part Number: 17827 Description: Spacer Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 59 Part Number: 35-8578 Description: Insert Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 60 Part Number: Comm. Description: Scr. Set Soc. 3/8-16NC x 1/2" Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 61 Part Number: Comm. Description: Nut, Jam 3/8-16NC Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 62 Part Number: 35-5473 Description: Post Clamp Ass'y. Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 63 Part Number: 35-8612 Description: Screw Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 64 Part Number: 6-01103 Description: Starwheel Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 65 Part Number: 4261 Description: Roll Pin Units Per Assembly: 1 Availability: In Stock Price: $1.28
Index No Ref.: 66 Part Number: 34698 Description: Poet AdJ. Sub. -Ass'y. Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 67 Part Number: 34687 Description: Shaft Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 68 Part Number: 4261 Description: Roll Pin Units Per Assembly: 1 Availability: In Stock Price: $1.28
Index No Ref.: 69 Part Number: 6-01103 Description: Starwheel Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 70 Part Number: 35-4191 Description: Post Shaft. Escutcheon Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 71 Part Number: Comm. Description: Scr., Ov. Hd. Mach. #10-24NC x 3/8" Units Per Assembly: 4 Availability: Call For Info Price:
Index No Ref.: 72 Part Number: 34690 Description: Post Lift Gear Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 73 Part Number: 13407 Description: Back-Up Washer Units Per Assembly: AR Availability: Call For Info Price:
Index No Ref.: 74 Part Number: 17827 Description: Spacer Washer Units Per Assembly: AR Availability: Call For Info Price:
Index No Ref.: 75 Part Number: 35-8610 Description: Hinge Pin Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Ref. Part Number: 44777 Description: Steel Rim Wheel Ass'y. Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: 76 Part Number: 44641 Description: Steel Rim Wheel Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 77 Part Number: Comm. Description: Screw, Drive #00 x 1/8" (Not Shown) Units Per Assembly: 2 Availability: Call For Info Price:
Index No Ref.: 78 Part Number: 17298 Description: Escutcheon (Not Shown) Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Ref. Part Number: 44579 Description: Taper Wheel Ass'y. Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: 79 Part Number: Comm. Description: Screw, Truss Hd. Mach. #10-24NC x 3/8" Units Per Assembly: 22 Availability: Call For Info Price:
Index No Ref.: 80 Part Number: 31452 Description: Back Up Plate Units Per Assembly: 6 Availability: In Stock Price: $56.30
Index No Ref.: 81 Part Number: 27437 Description: The & Rim Ass'y Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 82 Part Number: 4675 Description: Retainer Units Per Assembly: 2 Availability: In Stock Price: $17.45
Index No Ref.: 83 Part Number: 46931 Description: Taper Wheel Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: Ref. Part Number: 44577 Description: Crown Wheel Ass'y. Units Per Assembly: Availability: Call For Info Price:
Index No Ref.: 84 Part Number: 24939 Description: Rim & Tire Ass'y. Units Per Assembly: 1 Availability: Call For Info Price:
Index No Ref.: 85 Part Number: Comm. Description: Scr. Ov. Hd. Mach. 10-24NC x 3/8 Units Per Assembly: 4 Availability: Call For Info Price:
Index No Ref.: 86 Part Number: 4675 Description: Retainer Units Per Assembly: 2 Availability: In Stock Price: $17.45
Index No Ref.: 87 Part Number: 44578 Description: Wheel Units Per Assembly: 1 Availability: Call For Info Price:
